The ADDere SYSTEM II revolutionizes large-scale metal additive manufacturing, enhancing productivity with advanced laser wire technology. Capable of producing Titanium parts up to 80” x 40” x 40”, it features a powerful 20 kW laser and deposition rates of up to 20 lbs/hour. Real-time, closed-loop sensors ensure consistent quality, while an automated material handling system maintains an argon atmosphere for optimal performance.
The ADDere SYSTEM II revolutionizes large-scale metal additive manufacturing, enhancing productivity with advanced laser wire technology. Capable of producing Titanium parts up to 80” x 40” x 40”, it features a powerful 20 kW laser and deposition rates of up to 20 lbs/hour. Real-time, closed-loop sensors ensure consistent quality, while an automated material handling system maintains an argon atmosphere for optimal performance.
| Specification | Details |
|---|---|
| Built part size (LxWxH) | 2m x 1m x 1m / 80 x 40 x 40 in. |
| Built part weight (Max) | 1000 kg / 2200 lbs. |
| Laser power | 20 kW |
| 6-axis Industrial Robot | Yes |
| 2-axis work piece Positioner | Tilting axis ±90° | Rotational axis ±185° |
| Precision wire feeding solution | Complete |
| Deposition rate | Up to 30 lbs./h |
| Wall/Layer Size | Typical 5-6mm pass width and 1-2mm layer height |
| Sensor system Option | Real-time, closed-loop (IR weld pool monitoring, Integrated DSCS, Dynamic profiling sensor) control with WALS software package (optional) |
| Software package | ADDere by MWES |
| Safety enclosure | Class 1 |
